■ Through type of dimensions list
■ Blind type of dimensions list
■ Performance data（ Steel plate）
|
Performance →
|
Sheet
thickness （ｍｍ） |
Installation
（N) |
Pushout
(N) |
Torgue-out
（N・ｍ) |
|
Thread size↓
|
||||
|
M2
|
t=1.6
|
14700
|
980
|
2.45
|
|
M2.5
|
980
|
2.45
|
||
|
M3
|
1270
|
2.45
|
||
|
M4
|
1470
|
4.90
|
||
|
M5
|
1470
|
5.88
|
※They are not guarantee of the strength of our products.
